The Dual XVM279BT is a versatile 6.2-inch LED touchscreen car stereo receiver‚ offering Bluetooth connectivity‚ USB charging‚ and comprehensive functionality.
It’s designed for easy integration into most double-DIN openings‚ and professional installation is highly recommended for optimal performance.
Overview of the XVM279BT
The Dual XVM279BT is a 6.2-inch LED backlit multimedia touchscreen car stereo receiver designed to elevate your in-car entertainment experience. This Double DIN unit boasts a vibrant‚ full-color touchscreen interface for intuitive navigation and control.
Featuring built-in Bluetooth technology‚ the XVM279BT allows for seamless wireless audio streaming from your smartphone and hands-free calling. The rear USB port provides convenient device charging with a 1A output. It’s engineered for compatibility with 12VDC negative ground vehicles and offers a user-friendly experience. Access a complete owner’s manual at dualav.com/support/manuals.php for detailed guidance.
Key Features and Specifications
The Dual XVM279BT showcases a 7-inch full-color touchscreen display‚ providing a clear and responsive interface. Key features include integrated Bluetooth for audio streaming and hands-free calls‚ alongside a rear USB port delivering 1A charging capability.
This receiver fits most standard Double DIN openings and operates on a 12VDC negative ground system. The unit supports various audio formats via USB playback. Detailed specifications and comprehensive instructions are available in the downloadable installation and owner’s manual found on the official Dual website‚ dualav.com‚ ensuring a smooth setup and operation.
Installation Guide
Professional installation is strongly advised for the Dual XVM279BT due to its technical nature‚ ensuring correct wiring and optimal performance within your vehicle.
Safety Precautions
Before beginning installation‚ disconnect the vehicle’s negative battery terminal to prevent electrical shock and short circuits. Ensure the vehicle is parked on a level surface and the parking brake is engaged. This receiver is designed for 12VDC negative ground systems only; improper voltage can cause damage.
Avoid installing the unit in locations exposed to excessive moisture or dust. Do not attempt to disassemble or repair the unit yourself; refer servicing to qualified personnel. Always use appropriate tools and follow the wiring diagram carefully to prevent damage to the vehicle’s electrical system. Prioritize safety throughout the installation process.
Tools Required for Installation
For a successful installation of the Dual XVM279BT‚ you’ll need several tools. Essential items include a Phillips head screwdriver‚ a flathead screwdriver‚ wire strippers‚ and wire connectors. A crimping tool is highly recommended for secure connections. You may also require a socket set for removing the factory radio‚ and a panel removal tool to avoid damaging the dashboard.
A multimeter can be useful for testing voltage and continuity. Electrical tape is necessary for insulating connections. Consider a wiring harness adapter specific to your vehicle for a simpler‚ less intrusive installation process. Safety glasses are also advised.
Wiring Diagram
The Dual XVM279BT’s wiring involves connecting power‚ ground‚ speakers‚ antenna‚ and steering wheel controls. The red wire is for 12V constant power‚ the yellow wire for 12V switched power (ignition). A black wire provides the ground connection. Speaker wires typically follow a standard color code: white (left)‚ white/black (right)‚ green (front)‚ and purple (rear).
The blue/white wire controls the power antenna‚ and the orange/white wire is for illumination. Steering wheel control connections require a specific adapter harness. Refer to the detailed wiring diagram in the owner’s manual or on Dual’s website for precise connections.
Mounting the Receiver
Mounting the Dual XVM279BT requires a compatible double-DIN opening in your vehicle’s dashboard. Use the provided mounting brackets to secure the receiver within the opening. Ensure the brackets are firmly attached to both the receiver and the dashboard structure.
Carefully route all wiring behind the receiver to prevent interference with moving parts or potential damage. Double-check that all wires are securely connected before fully pushing the receiver into the dashboard. Professional installation is recommended to ensure a secure and proper fit.
Connecting the Antenna
To connect the antenna to your Dual XVM279BT‚ locate the antenna input jack on the rear of the receiver. Carefully plug the antenna cable into this jack‚ ensuring a secure connection. A properly connected antenna is crucial for optimal radio reception.
If your vehicle has a powered antenna‚ the receiver will automatically supply power to it. For vehicles with a standard antenna‚ ensure the antenna cable is undamaged and properly grounded. Verify signal strength after connection for best results.
Connecting the Steering Wheel Controls
To retain steering wheel control functionality with your Dual XVM279BT‚ a specific adapter interface is typically required‚ sold separately. Consult a professional installer to determine the correct adapter for your vehicle’s make and model. Connect the adapter’s wiring harness to both the vehicle’s steering wheel control wires and the designated port on the XVM279BT.
Proper connection allows you to control volume‚ track selection‚ and other functions from your steering wheel. Refer to the adapter’s instructions for specific wiring configurations and programming procedures.
Basic Operation
The XVM279BT features an intuitive touchscreen interface for power‚ volume‚ source selection‚ and navigation. Familiarize yourself with its responsive controls for seamless use.
Powering On and Off
To power on the Dual XVM279BT‚ simply press and hold the power button located on the front panel. The unit will illuminate‚ displaying the Dual logo and initiating the boot-up sequence. Allow a few moments for the system to fully load.
To power off the receiver‚ press and hold the same power button again. A confirmation prompt may appear on the touchscreen; select “OK” or “Power Off” to confirm. The screen will darken‚ and the unit will shut down.
Automatic power off functionality is also included‚ activating after a period of inactivity to conserve battery life. Refer to the advanced settings for customization options.
Touchscreen Navigation
The Dual XVM279BT features a responsive 7-inch full-color touchscreen display for intuitive control. Navigation is primarily gesture-based: tap to select‚ swipe to scroll‚ and pinch to zoom where applicable.
Main menu icons are clearly labeled and located at the bottom of the screen‚ providing quick access to core functions like radio‚ Bluetooth‚ USB‚ and settings. Explore each menu by tapping its corresponding icon.
Contextual menus appear as needed‚ offering specific options related to the currently selected function. A ‘back’ button is consistently displayed for easy navigation to previous screens.
Volume Control and Muting
Adjusting the volume on the Dual XVM279BT is straightforward. Utilize the dedicated volume knob‚ or tap the volume icon on the touchscreen display. Swipe up or down on the icon to increase or decrease the audio level‚ respectively.
Muting the audio is achieved by pressing and holding the volume knob for approximately two seconds. A mute icon will appear on the screen‚ confirming the action.
To unmute‚ repeat the process – press and hold the volume knob again. Volume levels are retained even after powering the unit off and on.
Source Selection (Radio‚ Bluetooth‚ USB)
Selecting your desired audio source on the Dual XVM279BT is easily done through the touchscreen interface. Tap the “Source” icon‚ typically located on the main menu. This will present you with a list of available options: Radio‚ Bluetooth‚ and USB.
To listen to the radio‚ select “Radio” from the list. For wireless audio streaming‚ choose “Bluetooth” after a device has been paired.
USB playback is initiated by selecting “USB” when a compatible device is connected. The unit will automatically detect and display available files.
Bluetooth Connectivity
The XVM279BT features built-in Bluetooth‚ enabling wireless audio streaming and hands-free calling. Pairing is simple via the touchscreen interface for convenient use.
Pairing a Device
To pair a Bluetooth device with your Dual XVM279BT‚ first ensure the receiver is powered on and in Bluetooth mode. Access the Bluetooth settings through the touchscreen navigation menu. Initiate the pairing process on the XVM279BT‚ and the system will begin searching for available devices.
On your smartphone or other Bluetooth-enabled device‚ enable Bluetooth and scan for available devices. Select “XVM279BT” from the list of discovered devices. You may be prompted to enter a pairing code (typically “0000” if required). Once the code is entered correctly‚ the devices will be paired. The XVM279BT will store paired devices for future automatic connection.
Bluetooth Audio Streaming
Once a device is paired via Bluetooth‚ you can enjoy wireless audio streaming. Select “Bluetooth Audio” as the source on the XVM279BT. Begin playing music or other audio content on your paired smartphone or device. The audio will automatically transmit to the receiver and play through your vehicle’s speakers.
Use the touchscreen controls on the XVM279BT to adjust the volume‚ skip tracks‚ pause‚ or play. Some devices may also allow control through the device itself. Ensure your Bluetooth device’s volume is also appropriately adjusted for optimal sound quality. Enjoy seamless audio playback!
Hands-Free Calling
The Dual XVM279BT enables convenient hands-free calling when paired with a Bluetooth-enabled smartphone. After successful pairing‚ incoming calls will automatically interrupt audio playback. The caller ID may be displayed on the touchscreen‚ if supported by your phone.
Answer calls by tapping the “Answer” icon on the touchscreen. To end a call‚ tap the “End Call” icon. Utilize the volume controls to adjust the call volume. The built-in microphone facilitates clear communication. Prioritize safety by keeping your focus on the road while using this feature.
Bluetooth Troubleshooting
If you experience Bluetooth connection issues with the Dual XVM279BT‚ first ensure your device is in pairing mode and within range. Delete previous pairings from both the receiver and your device‚ then attempt to re-pair. Confirm your phone’s Bluetooth is enabled and discoverable.
Interference from other wireless devices can sometimes disrupt the connection. Try moving away from potential sources of interference. If problems persist‚ consult the owner’s manual’s troubleshooting section or visit Dual’s support website for further assistance. A factory reset of the XVM279BT may also resolve connectivity problems.
Radio Functionality
The XVM279BT allows tuning to radio stations and managing preset stations easily. Explore radio mode settings for personalized listening experiences within the unit.
Tuning to Stations
To tune to radio stations on your Dual XVM279BT‚ begin by selecting the “Radio” source from the main menu using the touchscreen navigation. You can then scan for available stations by pressing the “Seek” or “Tune” buttons on the display.
These buttons will automatically search for the next available station. Alternatively‚ you can manually enter a frequency using the numeric keypad if you know the station’s dial position. The XVM279BT supports both AM and FM frequencies‚ providing a wide range of listening options. The receiver displays station information‚ including call letters and program type‚ when a station is tuned.
Preset Station Management
The Dual XVM279BT allows you to save your favorite radio stations as presets for quick access. To store a station‚ tune to the desired frequency and then press and hold one of the numbered preset buttons (1-6) until a confirmation tone sounds.
To recall a preset station‚ simply tap the corresponding preset button on the touchscreen. You can overwrite existing presets by following the same storage procedure. This feature eliminates the need to repeatedly search for your preferred stations‚ enhancing your listening experience while driving.
Radio Mode Settings
The Dual XVM279BT offers several settings to customize your radio experience. Access these options through the main menu and select “Radio Settings.” Here‚ you can adjust features like Seek Sensitivity‚ which determines how aggressively the receiver searches for stations.
You can also enable or disable Regional Programming‚ influencing station display based on location. Area Code Programming allows for localized station information. Explore these settings to optimize radio reception and tailor the listening experience to your preferences‚ ensuring clear and enjoyable audio quality.
USB Playback
The XVM279BT supports various file formats via USB‚ allowing for convenient music playback and device charging with its rear USB port.
Supported File Formats
The Dual XVM279BT offers broad compatibility when it comes to USB playback‚ ensuring a diverse range of audio files can be enjoyed during your travels. While a definitive list isn’t explicitly detailed in readily available documentation‚ the receiver generally supports commonly used digital music formats;
Expect compatibility with MP3‚ the industry standard for compressed audio‚ and WAV files‚ offering uncompressed audio quality. It’s likely to also support FLAC‚ a lossless audio codec for audiophiles seeking high fidelity sound. However‚ compatibility with other less common formats like AAC or WMA may vary.
For optimal performance‚ it’s recommended to use files encoded with standard settings and to ensure the USB drive is formatted with a FAT32 file system.
Navigating USB Files
Once a USB drive is connected to the Dual XVM279BT‚ accessing your music is straightforward via the touchscreen interface. The receiver typically displays a file browser‚ allowing you to navigate through folders and select your desired audio tracks.
You can usually browse by folder structure‚ or view all files at once. The touchscreen allows for easy scrolling and selection. Playback controls – play‚ pause‚ skip forward‚ skip backward‚ and repeat – are readily accessible on the screen.
The system may also offer options for random playback (shuffle) and displaying song information‚ if available in the file’s metadata.
Charging Devices via USB
The Dual XVM279BT features a rear USB port capable of providing 1A charging current for your mobile devices. This allows you to conveniently charge smartphones‚ tablets‚ or other USB-powered accessories while driving.
Simply connect your device to the USB port using a standard USB cable. Charging will commence automatically‚ though the charging speed may vary depending on the device’s power requirements.
Note that simultaneous audio playback from a USB drive and device charging may slightly reduce charging speed. Ensure the cable is securely connected for optimal charging performance.
Advanced Settings
Customize your experience with adjustable display settings‚ audio equalization‚ balance‚ fader controls‚ and system preferences like language and time.
Display Settings (Brightness‚ Contrast)
Adjusting the display is crucial for optimal visibility in varying lighting conditions. The Dual XVM279BT allows users to fine-tune both brightness and contrast levels directly through the touchscreen interface.
Increasing brightness enhances visibility during daylight hours‚ while decreasing it reduces glare at night. Contrast adjustments impact the clarity between light and dark elements on the screen. Experiment with these settings to achieve a comfortable viewing experience tailored to your preferences and the ambient light.
Remember‚ a well-adjusted display minimizes eye strain and maximizes readability while driving.
Audio Settings (EQ‚ Balance‚ Fader)
Personalize your listening experience with the XVM279BT’s comprehensive audio controls. The built-in equalizer (EQ) allows you to adjust specific frequency bands‚ boosting bass‚ enhancing vocals‚ or refining treble to match your musical taste.
Balance controls shift the sound distribution between the left and right speakers‚ while the fader adjusts the sound between the front and rear speakers. These adjustments ensure optimal sound staging within your vehicle’s cabin. Experiment with these settings to create a perfectly balanced and immersive audio environment.
System Settings (Language‚ Time)
Customize the XVM279BT to your preferences through the System Settings menu. You can select your preferred display language‚ ensuring the interface is easy to navigate and understand. Accurate timekeeping is also crucial; the system settings allow you to manually set the current time or enable automatic time synchronization if a compatible signal is available.
These settings enhance usability and ensure the receiver operates seamlessly within your vehicle. Accessing these options through the touchscreen interface is straightforward‚ providing a personalized user experience.
Troubleshooting
Before seeking service‚ consult the owner’s manual troubleshooting guide for solutions to common issues like no power‚ sound‚ or Bluetooth connectivity problems.
No Power
If the XVM279BT fails to power on‚ first verify the vehicle’s ignition is switched to the accessory or on position. Check the receiver’s fuse – both the unit’s internal fuse and the vehicle’s fuse box related to the audio system.
Ensure all wiring connections‚ particularly the 12VDC power and ground wires‚ are secure and properly connected. A loose or incorrect connection is a frequent cause.
Confirm the receiver is compatible with your vehicle’s 12VDC negative ground electrical system. If the problem persists‚ professional installation diagnosis is advised.
No Sound
If you experience no sound from the Dual XVM279BT‚ begin by verifying the volume level isn’t muted or set too low. Check the source unit’s audio output settings‚ ensuring the correct audio source (radio‚ Bluetooth‚ USB) is selected and active.
Inspect the speaker wiring connections to confirm they are secure and correctly connected to both the receiver and the speakers. Verify the vehicle’s speaker fuse hasn’t blown.
Adjust any equalizer (EQ) settings; extreme settings can sometimes suppress audio output. If issues remain‚ consult a professional for diagnosis.
Bluetooth Connection Issues
Experiencing Bluetooth connectivity problems? First‚ ensure Bluetooth is enabled on both your XVM279BT and your mobile device. Verify your device is within range of the receiver. Attempt to “forget” or unpair the device from both the receiver and your phone‚ then re-pair them following the pairing instructions.
Check for interference from other Bluetooth devices. Restarting both the receiver and your mobile device can often resolve connection glitches. If problems persist‚ consult the troubleshooting section of the full owner’s manual available online.
Touchscreen Responsiveness
If the touchscreen isn’t responding‚ first ensure the screen is clean and free of debris. Gently wipe it with a soft‚ dry cloth. A recalibration of the touchscreen might be necessary; check the advanced settings menu within the XVM279BT for this option.
Restarting the unit can often resolve temporary software glitches affecting responsiveness. If the issue continues‚ consult the comprehensive troubleshooting guide in the owner’s manual‚ downloadable from the official Dual website. A slight adjustment of custom controls may resolve the issue.
Manual Download and Support
Access a complete owner’s manual and support resources at www.dualav.com/support/manuals.php. Customer service is available at 1-866-382-5476.
Official Dual Website for Manuals
The official Dual website serves as the primary hub for accessing comprehensive documentation related to the XVM279BT. Users can conveniently download the complete owner’s manual in PDF format directly from www.dualav.com/support/manuals.php.
This online resource provides detailed instructions covering installation procedures‚ operational guidelines‚ troubleshooting tips‚ and safety precautions. Regularly checking the website ensures access to the most up-to-date information‚ including potential firmware updates or revised documentation.
The downloadable manual offers a thorough understanding of all features and functionalities of the XVM279BT‚ empowering users to maximize their experience with the device.
Customer Support Contact Information
For direct assistance with your Dual XVM279BT‚ dedicated customer support is readily available. Users can reach the Dual support team by calling 1-866-382-5476. This phone line provides a direct connection to knowledgeable representatives who can address inquiries‚ offer troubleshooting guidance‚ and assist with any operational challenges.
Beyond phone support‚ the official Dual website – www.dualav.com – offers additional contact options‚ potentially including email support or a live chat feature.
Before contacting support‚ reviewing the online manual may resolve common issues quickly.
Frequently Asked Questions (FAQ)
Q: Where can I find the complete owner’s manual? A: A comprehensive manual is available for download at www.dualav.com/support/manuals.php. This provides detailed instructions for installation‚ operation‚ and troubleshooting.
Q: What should I do if the unit won’t power on? A: Check the vehicle’s fuse and the receiver’s wiring connections. Ensure a proper 12VDC negative ground connection.
Q: I’m experiencing Bluetooth connection issues. A: Verify Bluetooth is enabled on both devices‚ and try re-pairing. Refer to the Bluetooth troubleshooting section for further assistance.
Q: Can I adjust custom controls to avoid a service call? A: Yes‚ slight adjustments to custom settings may resolve minor issues.
